Ebflow Light

Ebflow light combines the benefits of laser welding in a vacuum, including deep penetration welding and exceptional quality, with CVE’s patented local vacuum systems.

This enables large fabrications to be welded on-site, with a thickness of up to 60mm achievable in a single pass.

In addition, weld speeds of up to 30 times faster than those achieved by arc welding processes are achievable.

Benefits of Local Vacuum

Improved weld penetration depth for a given power
Better weld quality, low porosity, and spatter
Reduced consumption of expensive process gas
Self-contained laser safety – no cell required
Less demanding vacuum conditions than electron beam
Immune to magnetism issues

Specification

Beam Power	6kW
Depth of Weld	Up to 60mm
Vacuum Range	10^-1 – 10^-2mbar range

Benefits of Local Vacuum

Improved weld penetration depth for a given power
Better weld quality, low porosity, and spatter
Reduced consumption of expensive process gas
Self-contained laser safety – no cell required
Less demanding vacuum conditions than electron beam
Immune to magnetism issues

Specification

Beam Power	6kW
Depth of Weld	Up to 60mm
Vacuum Range	10^-1 – 10^-2mbar range

Ebflow Light Explainer Video
